Shift knob sensor with 1 to 3 channel force : BDYN-060
The dynamometric pedal called PEDYN-40 is designed in partnership with the automotive industry instrumentation design office.
The posssibility of being in capacity to measure simultaneously 3 forces makes it possible to evaluate the efficiency of braking force.
- Dynamometric shift knob sensor during gear switch operation by the driver. Measurement from 1 to 3 channel force.
- Range of measuremente : +/-20 daN to +/- 50daN
- Sensitivity: from 1,00 to 1,5 mV/V according to full scale design.
- Standard accuracy : 0,35% for each channel / interaction between channel <2,0%
- Matérial : stainless steel for the sensor and composite or bakelite for the cap
- Protection index : IP52 (possibility to reinforce the IP)
- Option: high-level electronic output integrated in the pedal or in small separated housing : 0-10V, 0-5.0V, 4-20mA et USB digital
