Programmable via 3 keys on the front panel with very use friendly menu
-Display in "follower" mode, storage of minimum and maximum peaks
-Display +/- 19,999 points
-Stabilized power supply for sensor power supply with gauge bridge: 5.00V or 10.00V
-Process voltage and current, temperature
-Linearization up to 10 segments
-3 display colors
-Power supply: BT 10.5 to 70 VDC or HT 85-265VAC
-Configurable functions 3 inputs with 12 programmable logic functions
Options: relay card with 2 or 4 programmable thresholds, RS232, RS485, MODBUS RTU communication card,
0-10Vc or 4-20mA analog output card
|
|
Programmable via 5 keys on the front panel with very use friendly menu
-Display in "follower" mode, storage of minimum and maximum peaks
-Sampling rate conversion : 555 samples/second
-Large technical features configurations for force, torque, pressure, motion transducer
-Process voltage 0-10.0V and current +/-20mA ,
-Power supply: BT 10.0 to 30 VDC or HT 115-235VAC
-Operational temperature : -10°C ;+60°C
Options: relay card with 2 or 4 programmable thresholds, RS232, RS485, MODBUS RTU communication card,
0-10Vc or 4-20mA analog output PC board
|
|
Programmable via 5 keys on the front panel with very use friendly menu
-Display in "follower" mode, storage of minimum and maximum peaks
-Display +/- 99,999 points, 2 LED displays
-Large technical features configurations for strain gauges applications
-Process voltage and current, temperature :thermocouple, J,K,T,R,S,E or Pt100
-Linearization up to 30 segments
-3 display colors
-Power supply: BT 10.5 to 70 VDC or HT 85-265VAC
-Configurable functions 4 inputs with 36 programmable logic functions
Options: relay card with 2 or 4 programmable thresholds, RS232, RS485, MODBUS RTU communication card,
0-10Vc or 4-20mA analog output card
|
|
